Esp32 S3 ESP32-S3 4inch Capacitive Touch Display Development Board, 480×480, 5 Esp32 S3 Amoled 1.8

Dettagli prodotto

Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gesture, counting steps, etc. Type-C connector, improving device compatibility, easier to use Onboard 1.8inch AMOLED display for clear color picture display, 368 x 448 resolution, 16.7M color. ESP32 S3 Touch AMOLED 1.8 is a low cost, high performance MCU board designed by , tiny size, with onboard 1.8inch AMOLED display, power management IC, 6 axis sensor (3 axis accelerometer and 3 axis gyroscope), RTC, low power audio codec, and so o Esp32 S3 ESP32-S3 4inch Capacitive Touch Display Development Board, 480×480, 5 Esp32 S3 Amoled 1.8 Onboard PCF85063 RTC chip, powered by main Lithium battery through AXP2101 chip, with reserved RTC battery pads for connecting a backup battery, ensuring RTC function during the replacement of the main battery. Onboard 3.7V MX1.25 Lithium battery recharge/discharge header, Support 3.7V Lithium battery(Included) Onboard TF card slot for extended storage and fast data transfer, suitable for applications such as data recording and media playback, simplifying circuit design Built-in SH8601 display driver and FT3168 capacitive touch chip, using QSPI and I2C communication respectively, effectively saving the IO resources. Reserved pads of 7 x GPIO, 1 x I2C, 1 x UART, and 1 x USB interface, for connecting peripherals and debugging. Built in 512KB of SRAM and 384KB ROM, with onboard 8MB PSRAM and an external 16MB Flash memory.
